SECTION 2 - GROUND COMPONENTS
3121682
2032ES/2632ES
71
FIGURE 2-9. GROUND CONTROL BOX ASSEMBLY - LSS (ALL SPECS EXCEPT CE) (USA BUILT
MACHINES)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001166197
Ref
GROUND CONTROL BOX ASSEMBLY - LSS (ALL SPECS
EXCEPT CE)
B
1
0380025
1
Base, Box
2
0610161
1
PC Board, Charger LED
2
4460321
1
Plug, Male - 4 Position
2
4460268
3
Socket, Female
3
1671105
1
Cover
4
1705697
1
Decal
5
1705698
1
Decal
6
2420172
1
Hourmeter
7
2920026
1
Lamp
8
2920094
1
Bulb
9
3321005
4
Nut #10-32
10
3900336
6
Screw
11
3900338
6
Screw
12
3900339
2
Screw
13
1001180090
4
Screw M3.5 X 20
14
1001165315
1
Support
15
4360069
1
Breaker, Circuit 10A
16
4360328
1
Switch,Toggle
17
4360469
1
Switch, Key
17
2860030
1
Key, Replacement
18
4360475
1
Switch, Emergency Stop
18
7020175
1
Cap
18
7020176
1
Block, Contact
19
4751000
4
Washer #10
20
1001166255
1
Sensor, Tilt (Includes Sensor, Mounting Plate & Hardware)
21
1001167256
1
Harness, Ground Control Box (See ELECTRICAL SECTION for
Breakdown)
22
1001114937
1
Mount, Harness
23
1001165284
1
Fastener
24
1001165286
1
Spacer
