SECTION 2 - GROUND COMPONENTS
3121682
2032ES/2632ES
73
FIGURE 2-10. GROUND CONTROL BOX ASSEMBLY - LSS (ALL SPECS EXCEPT CE) (CHINA BUILT
MACHINES)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001114932
Ref
GROUND CONTROL BOX ASSEMBLY - LSS (ALL SPECS
EXCEPT CE SPECS)
A
1
0380025
1
Box, Ground Control
2
0610161
1
Board, PC (Battery Charger LED)
3
1671105
1
Cover, Front
4
1705697
1
Decal - LED
5
1705698
1
Decal - Function
6
2420172
1
Hourmeter
7
2920026
1
Lamp
7
2920094
AR
Bulb
8
3900336
6
Screw #10-32NF x 1/2
9
3900338
6
Screw M4 x 20
10
3900339
2
Screw #6 x 1/2
11
3900356
4
Screw M3.5 x 16
12
4340739
1
Plate, Mounting
13
4360069
1
Breaker, Circuit - 10 Amp
14
4360328
1
Switch, Toggle
15
4360469
1
Keyswitch
15
2860030
1
Key, Replacement (Fits All Specs)
16
4360475
1
Switch, Emergency Stop
16
7020175
1
Cap
16
7020176
1
Block, Contact
17
1001114933
1
Module, Tilt (Includes Module and Mounting Plate and Hardware)
18
1001114937
1
Mount, Harness Bulkhead (Ground Control)
19
3321005
4
Nut #10-32NF
20
4751000
4
Washer #10
21
1001114935
1
Harness, Control Box (See ELECTRICAL SECTION for
Breakdown)
