SECTION 7 - ELECTRICAL
3121682
2032ES/2632ES
239
FIGURE 7-12. CABLES INSTALLATION - 2032ES ALL SPECS EXCEPT AUSTRALIAN/CE SPECS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001178318
Ref
CABLES INSTALLATION - 2032ES ALL SPECS EXCEPT
AUSTRALIAN/CE SPECS
A
1
0100048
AR
Compound, Sealing
2
0760610
2
Bolt M6 X 20
3
1321716
2
Clamp
4
1380158
13
Clip, Retainer
5
3290601
2
Nut M6
6
3290605
2
Nut M6
7
3290606
1
Nut M6
8
4010616
1
Screw M6 X 40
9
4031713
2
Capscrew M6 X 45
10
4740545
5
Washer
11
4751400
2
Washer 1/4
12
1001178687
1
Ground to Platform Cable (See GROUND TO PLATFORM CABLE
ASSEMBLY - 2032ES ALL SPECS EXCEPT AUSTRALIAN/CE
SPECS for Breakdown)
13
1001094175
1
Clamp
14
1001096706
1
Platform Cable (See PLATFORM CABLE ASSEMBLY for
Breakdown)
15
1001096794
1
Pump Power Cable (See PUMP POWER CABLE ASSEMBLY for
Breakdown)
16
1001115002
1
Cylinder Harness Assembly (See CYLINDER HARNESS
ASSEMBLY for Breakdown)
17
1001155042
5
Tie-Strap
18
1001178317
1
Battery Cable Kit (See BATTERY CABLE KIT for Breakdown)
19
1001178496
1
Chassis Harness Assembly (See CHASSIS HARNESS
ASSEMBLY for Breakdown)
