SECTION 3 - BOOM
3121254
E300AJ/E300AJP
79
FIGURE 3-7. CABLE, CLAMPS AND LIMIT SWITCHES INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
BOOM CABLE CLAMPS INSTALLATION
1001109562
Ref
Boom Cable Clamps Installation E300AJ
D
1001109563
Ref
Boom Cable Clamps Installation E300AJP
D
Ref
Note: See Main Boom Assembly for Additional Components.
1
0100011
AR
Compound, Locking
2
0641416
6
Bolt 1/4in-20NC x 2in
3
0641511
1
Bolt 5/16in-18NC x 1-3/8in
4
0721006
1
Screw #10-24NC x 3/4in
5
1320043
1
Clamp
6
1320261
6
Clamp
7
1320262
1
Clamp
8
1670899
1
Cover
9
3311005
1
Locknut #10-24NC
10
3311405
6
Locknut 1/4in-20NC
11
3930820
2
Capscrew #10-24NC x 1-1/4in
12
3930828
2
Capscrew #10-24NC x 1-3/4in
13
4060808
31
in/79cm
Flex Trim
14
4711400
6
Flatwasher 1/4in Thin
15
4751400
2
Flatwasher 1/4in Regular
16
8750011
1
Bolt, Stacking
21
1001109814
1
Harness, Boom (Includes Limit Switches) (See ELECTRICAL
SECTION for Breakdown)
22
1320159
1
Clamp
23
4240156
2
Strap, Cinch
24
4240033
AR
Tie-Strap
25
4240018
AR
Tie-Strap
26
3310805
4
Locknut #8-32NC
27
4750800
4
Flatwasher #8 Regular
28
1320130
1
Clamp (E300AJ Only)
29
0641608
1
Bolt 3/8in-16NC x 1in (E300AJ Only)
30
3311605
1
Locknut 3/8in-16NC (E300AJ Only)
31
4751600
2
Flatwasher 3/8in Regular (E300AJ Only)
32
4100066
2
Sleeve, Hose Wrap
