SECTION 3 - BOOM
3121254 E300AJ/E300AJP 75
FIGURE 3-5. PLATFORM ROTATOR ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION REV
0060044 Ref PLATFORM ROTATOR ASSEMBLY D
Ref Note: There are 2 different versions of Rotator p/n 0060044
and no SN break exists. Order internal parts by the Helac
Control #.
1 0060044 1 Case/Bracket Weldment (Note: Not available for purchase)
1A 0962257 2 Bushing, Garmax
1B 0961947 2 Bushing, Garmax
2 Ref Shaft Options:
2 7017120 1 Helac Control #25928
2 7017196 1 Helac Control #26962
3 Ref Sleeve, Piston Options:
3 7017121 1 Helac Control #25928
3 7027900 1 Helac Control #26962
4 Ref Cap, End
4 0060044 1 Helac Control #25928 (Note: Not available for purchase)
4 7027901 1 Helac Control #26962
5 See Note 3 Capscrew 1/4in-20NC (Grade 8) (Note: Not Available for
Purchase)
7 7017126 1 Tie Rod Assembly
20 See Note 1 Seal, Rod (Note: Use Item 52)
22 See Note 1 Seal, Piston (Note: Use Item 52)
24 See Note 1 Seal, Cap (Note: Use Item 52)
25 See Note 2 Packing, Bearing (Note: Use Item 52)
26 See Note 2 Seal (Note: Use Item 52)
27 See Note 1 Ring, Cap Back-Up (Note: Use Item 52)
32 7017122 2 Bearing, Shaft
34 7017122 2 Thrustwasher
41 7017172 1 Counterbalance Valve Assembly
41 7017192 2 Cartridge, Valve (No Seal Kit Available)
42 See Note 2 Bushing, Shaft (Note: Not available for purchase)
51 7017122 1 Bearing Kit (Includes Items 32 & 34):
52 Ref Seal Kit Options (Includes Items 20, 22, 24, 25, 26 & 27):
52 7017127 1 Standard
52 70000341 1 Cold Climate
53 7017123 1 Hardware Kit
54 70001697 4 Screw, Countersunk 1/4in-20NC x 3/8in (Grade 8)
