SECTION 5 - CYLINDER

3121254

E300AJ/E300AJP

115

FIGURE 5-6. STEER CYLINDER ASSEMBLY

ITEM

PART NUMBER

QTY

DESCRIPTION

REV

1001108310

Ref

STEER CYLINDER ASSEMBLY

C

1

70002384

1

Barrel Weldment

2

70002383

1

Rod Weldment

3

70002382

1

Head

4

70002379

1

Wiper

5

70002373

1

Ring, Retaining

6

70002379

1

Seal, Rod

7

70002379

1

Ring, Back-up

8

70022586

1

Ring, Wear

9

70002379

1

O-Ring

10

70002379

1

Ring, Back-up

11

70002379

1

O-Ring

12

70002381

1

Piston

13

70002379

1

Seal, Piston

14

70002379

1

O-Ring

15

70002335

1

Nut

15

0100071

AR

Compound, Locking

16

70002363

2

Bearing

17

70002380

2

Bearing

100

70002379

1

Seal Kit (Includes Items 4, 6, 7, 9, 10, 11, 13 & 14)
