Page 11
SECTION 1 - FRAME
3121254
E300AJ/E300AJP
11
FIGURE 1-1. STEER INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001108599
Ref
STEER INSTALLATION
C
1
0100011
AR
Compound, Locking
2
0641607
2
Bolt 3/8in-16NC x 7/8in
3
3312005
3
Locknut 5/8in-11NC
4
3422181
1
Pin
5
3422562
2
Pin
6
3841143
3
Keeper, Pin
7
3900118
2
Screw, Shoulder
8
3900255
1
Capscrew, Shoulder 3/4in x 3in
9
1001107712
2
Hub/Spindle Assembly (See Items 101-115 for Breakdown)
10
1001107727
1
Tie-Rod
11
1001108310
1
Steer Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
12
4740086
2
Thrustwasher
13
0440162
4
Thrustwasher
14
0641610
1
Bolt 3/8in-16NC x 1-1/4in
15
3311605
1
Locknut 3/8in-16NC
16
4711600
1
Flatwasher 3/8in Thin
17
1001151428
AR
Plate, Shim (SN 0300176716 to Present)
1001107712
Ref
HUB/SPINDLE ASSEMBLY
A
Ref
Note: Qty shown is for 1 Hub Assembly. Machine requires 2
assemblies.
101
7020137
1
Cap, Dust
102
0961951
2
Bushing, Garmax
103
0962140
1
Bearing, Garmax
104
70002434
1
Hub
105
7020036
1
Cup, Bearing (Inner) (Part of Item 104)
106
7020037
1
Cone, Bearing (Inner)
107
7020038
1
Cup, Bearing (Outer) (Part of Item 104)
108
7020039
1
Cone, Bearing (Outer)
109
70002435
1
Spindle
110
7020140
1
Pin, Cotter
111
7020040
1
Seal
112
7020054
1
Nut, Castle 1-1/4in-12
113
7020041
9
Stud 5/8in-18NF
114
7020042
9
Lugnut 5/8in-18NF
115
7020055
1
Washer, Tanged 1-1/4in
