SECTION 2 - TURNTABLE
3121254 E300AJ/E300AJP 57
FIGURE 2-10. HOOD INSTALLATION (SN 0300194887 to Present)
ITEM PART NUMBER QTY DESCRIPTION REV
1001164606 Ref HOODS INSTALLATIONS (SN 0300194887 to Present) C
1 0100011 AR Compound, Locking
2 0641606 8 Bolt 3/8in-16NC x 3/4in
3 4751600 8 Flatwasher 3/8in Regular
4 1001164239 1 Hood Assembly - LH (See Items 101-108 for Breakdown
5 1001164280 1 Hood Assembly - RH (See Items 201-204 for Breakdown)
6 2560122 1 Handle
7 2560123 1 Grip, Handle
8 0940036 2 Door, Bumper
1001164239 Ref HOOD ASSEMBLY - LH F
101 0721005 2 Screw #10-24NC x 5/8in
102 1380136 2 Clip, Gripper
103 2600258 2 Hinge
104 2940117 1 Latch
105 3311005 2 Locknut #10-24NC
106 4751200 2 Washer,12 Dia Plain Stl
107 1001164238 1 Hood Steel - LH
108 3820020 6 Rivet, Pop
1001164280 Ref HOOD ASSEMBLY - RH E
201 2600258 1 Hinge
202 2940117 1 Latch
203 3820020 1 Rivet, Pop (Not Shown)
204 1001164257 1 Hood Steel - RH
