SECTION 3 - BOOM
62 E300AJ/E300AJP 3121254
ITEM PART NUMBER QTY DESCRIPTION REV
27 1001108387 1 Tower Boom Assembly E300AJ
27 1001107583 1 Tower Boom Assembly E300AJP
28 Ref Jib Assembly (See JIB ASSEMBLY AND PLATFORM SUPPORT
INSTALLATION for Breakdown)
28 1001107615 1 Jib Assembly (Use p/n 1001125318) E300AJ (SN 0300138358
through 0300157823)
28 1001123025 1 Jib Assembly (Use p/n 1001125318) E300AJ (SN 0300157824
to Present)
28 1001107614 1 Jib Assembly (Use p/n 1001123024) E300AJP (SN
0300138358 through 0300157823)
28 1001123024 1 Jib Assembly E300AJP (SN 0300157824 to Present)
29 3422709 1 Pin
30 1001109528 1 Pin
31 Ref Bolt Options:
31 0641609 1 3/8in-16NC x 1-1/8in (SN 0300138358 through 0300157823)
31 0761014 1 M10 x 30mm (SN 0300157824 to Present)
32 Ref Bolt Options:
32 0641607 1 3/8in-16NC x 7/8in (SN 0300138358 through 0300157823)
32 0761011 1 M10 x 22mm (SN 0300157824 to Present)
