SECTION 5 - CYLINDER
3121254
E300AJ/E300AJP
111
FIGURE 5-4. LIFT (TOWER BOOM) CYLINDER ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001107886
Ref
LIFT (TOWER BOOM) CYLINDER ASSEMBLY
D
1
70002340
1
Barrel Weldment
2
70002339
1
Rod Weldment
3
70002338
1
Head
4
70002332
1
Wiper
5
70002410
1
Ring, Retaining
6
70002332
1
Seal, Rod
7
70002332
1
Ring, Back-up
8
70002337
1
Ring, Wear
9
70002332
1
O-Ring
10
70002332
1
Ring, Back-up
11
70002332
1
O-Ring
12
70002336
1
Piston
13
70002332
1
Seal, Piston
14
70002332
1
O-Ring
15
70002335
1
Nut
15
0100071
AR
Compound, Locking
16
70002387
1
Cartridge, Valve (Counterbalance)
16
2900770
1
Seal Kit - 70002387 Valve (1 Per Assembly)
17
7024884
1
Cartridge, Valve (2 Way Poppet)
17
7012967
1
Seal Kit - 7024884 Valve (1 Per Assembly)
17
70002386
1
COIL
18
7012955
1
Cartridge, Valve (Check)
18
7012967
1
Seal Kit - 7012955 Valve (1 Per Assembly)
19
See Note
3
Plug, O-Ring(Note: Not available for purchase)
20
70002334
1
Orifice
21
70002333
2
Bearing
23
70002409
2
Bearing
100
70002332
1
Seal Kit (Includes Items 4, 6, 7, 9, 10, 11, 13 & 14)
