SECTION 5 - CYLINDER
3121254
E300AJ/E300AJP
109
FIGURE 5-3. LIFT (MAIN BOOM) CYLINDER ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001106880
Ref
LIFT (MAIN BOOM) CYLINDER ASSEMBLY
E
1
70002349
1
Barrel Weldment
2
70002348
1
Rod Weldment
3
70002347
1
Head
4
70002341
1
Wiper
5
70002412
1
Ring, Retaining
6
70002341
1
Seal, Rod
7
70002341
1
Ring, Back-up
8
70022593
1
Ring, Wear
9
70002341
1
O-Ring
10
70002341
1
Ring, Back-up
11
70002341
1
O-Ring
12
70002346
1
Piston
13
70002341
1
Seal, Piston
14
70002341
1
O-Ring
15
70002345
1
Nut
15
0100071
AR
Compound, Locking
16
70002344
1
Spacer
17
70002341
1
O-Ring
18
70002387
1
Cartridge, Valve (Counterbalance)
18
2900770
1
Seal Kit - 70002387 Valve (1 Per Assembly)
19
7024884
1
Cartridge, Valve (2 Way Poppet)
19
7012967
1
Seal Kit - 7024884 Valve (1 Per Assembly)
19
70002386
1
Coil
20
7012955
1
Cartridge, Valve (Check)
20
7012967
1
Seal Kit - 7012955 Valve (1 Per Assembly)
21
See Note
3
Plug, O-Ring(Note: Not available for purchase)
22
70002343
1
Orifice
23
70002342
4
Bearing
100
70002341
1
Seal Kit (Includes Items 4, 6, 7, 9, 10, 11, 13, 14 & 17)
