SECTION 7 - ELECTRICAL
3121254 E300AJ/E300AJP 139
ITEM PART NUMBER QTY DESCRIPTION REV
706D)
0275219 1 0275717 Installation (Includes Items 706A, 706B, 706C &
706D) (Use p/n 1001100344)
0275454 0275713 Installation (Includes Items 706A, 706B, 706C &
706D)
1001110271 Ref INVERTER ELECTRICAL COMPONENTS (OPTIONAL) B
803 1060494 12 ft/3.7m Cable, Electrical - 12/3
804 1060801 1 Cable, Inverter (+)
805 1060802 1 Cable, Inverter (-)
814 4460035 1 Terminal, Butt
815 4460135 1 Receptacle, Female Twist-Lock
816 4460138 1 Plug, Male
817 4460426 1 Connector, Strain Relief
820 1001110449 1 Harness, Inverter
820A 4460320 1 Plug, Male - 2 Position
820A 4460227 2 Pin, Male
820B 4460424 1 Connector, Female - 2 Position
820B 4460226 2 Socket, Female
Ref TOOLS
901 7002821 1 Crimper (For Wire to Pin/Socket Connections) (Not Shown)
902 7002823 1 Extractor (For Removal of Pin/Socket from Connectors) (Not
Shown)
903 4460467 1 Extractor, Pin (Blue 16-18 Gauge) (For Removal of Pin/Socket
from Connectors) (Not Shown)
904 4460510 1 Extractor, Pin (Yellow 12-14 Gauge) (For Removal of Pin/Socket
from Connectors) (Not Shown)
905 7002828 1 Stripper, Wire (Not Shown)
906 2901443 1 Analyzer Kit (Not Shown)
906A 1600244 1 Analyzer
906B 1060633 1 Cable, Analyzer 1-A
906C 4460321 2 Plug, Male
906C 4460226 8 Socket, Female
907 1001137005 1 Software Cable Kit (Not Shown)
