SECTION 2 - TURNTABLE
3121254 E300AJ/E300AJP 39
FIGURE 2-3. BOOM FUNCTION VALVE ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION REV
Ref BOOM FUNCTION VALVE ASSEMBLY
1001109447 Ref Boom Function Valve Assembly E300AJ D
1001109446 Ref Boom Function Valve Assembly E300AJP D
1 70002405 1 Cartridge, Solenoid (Jib Lift)
1 7017402 1 Seal Kit - 70002405 Cartridge
2 7017452 3 Cartridge, Solenoid Valve (Telescope/Platform Rotate/Platform
Level and Master)
2 7017402 3 Seal Kit - 7017452 Cartridge
3 7017421 2 Cartridge, Relief Valve (Jib Lift/Platform Level and Master)
3 7012998 2 Seal Kit - 7017421 Cartridge
4 7017418 1 Cartridge, Relief Valve (Platform Level and Master)
4 7012998 1 Seal Kit - 7017418 Cartridge
5 7017489 1 Cartridge, Relief Valve (Jib Lift)
5 7012998 1 Seal Kit - 7017489 Cartridge
6 7012914 2 Cartridge, Pressure Control Valve
6 7012918 2 Seal Kit - 7012914 Cartridge
7 70002406 1 Cartridge, Manual Control Valve
7 7012904 1 Seal Kit - 70002406 Cartridge
7 7012959 1 Knob
8 70004019 1 Cartridge, Hand Pump Valve (was p/n 7012694)
8 7017496 1 Seal Kit - 7012694 Cartridge
8 2900756 1 Seal Kit - 70004019 Cartridge
9 7022391 1 Cartridge, Check Valve
9 7012967 1 Seal Kit - 7022391 Cartridge
10 4641129 1 Cartridge, Check Valve
10 7012540 1 Seal Kit - 4641129 Cartridge
11 7024885 10 Coil
12 70003528 2 Orifice
13 701706 8 Plug
14 Ref Cartridge Options:
14 Ref Cartridge E300AJ uses:
14 7017471 1 Cartridge
14 7017471 1 Seal Kit - 7017471 Cartridge (Note: Not Available for
Purchase)
14 Ref Cartridge E300AJP uses:
14 7017452 1 Cartridge, Solenoid (Jib Rotate)
14 7017402 1 Seal Kit - 7017452 Cartridge
