SECTION 6 - HYDRAULIC
3121254
E300AJ/E300AJP
121
FIGURE 6-1. HYDRAULIC DIAGRAM - E300AJ
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001109711
Ref
HYDRAULIC DIAGRAM - E300AJ
J
1
2220502
2
Fitting, 45 Elbow
2
2220466
3
Fitting, 90 Elbow
3
2220473
3
Fitting, 45 Elbow
4
2220472
8
Fitting, 45 Elbow
5
2220628
1
Fitting, 45 Elbow
6
2220909
2
Fitting, Orifice .015
7
2221033
2
Fitting, Straight
9
2220415
5
Fitting, Straight
11
2220582
16
Fitting, Straight
12
Ref
Fitting, Straight Options:
12
2220593
1
Fitting, Straight (SN 0300138358 through 0300177036)
12
2220408
1
Fitting, Straight (SN 0300177037 to Present)
13
2220372
10
Fitting, Straight
14
2221034
1
Fitting, Tee
15
2754055
1
Hose
16
2755023
1
Hose
17
1001109688
2
Hose
18
2753364
1
Hose
19
2753276
2
Hose
20
2753279
2
Hose
21
1001112946
2
Hose
22
1001109686
2
Hose
23
1001110728
1
Hose
24
1001109687
2
Hose
25
2752999
3
Hose
28
Ref
Hose Options:
28
1001109689
1
Hose (SN 0300138358 through 0300179560)
28
2752613
1
Hose (SN 0300179561 to Present)
29
2753137
1
Hose
30
2753136
1
Hose
31
1001109690
1
Hose
32
2753812
2
Hose
33
1001112947
1
Hose
34
Ref
Hose Options:
34
1001109691
1
Hose (SN 0300138358 through 0300177036)
34
1001160232
1
Hose (SN 0300177037 to Present)
35
1320030
1
Clamp
36
2221086
1
Fitting, Test Port
37
1001112948
4
Hose
38
2752473
1
Hose (SN 0300179561 to Present)
39
2221048
2
Fitting, Elbow (SN 0300179561 to Present)
