SECTION 1 - FRAME

3121254

E300AJ/E300AJP

27

FIGURE 1-7. FRAME COVERS INSTALLATION

ITEM

PART NUMBER

QTY

DESCRIPTION

REV

1001109383

Ref

FRAME COVERS INSTALLATION

C

1

0100011

AR

Compound, Locking

2

0641504

2

Bolt 5/16in-18NC x 1/2in

3

1380138

3

Nut, Clip

4

1704246

1

Decal - Cable Routing

5

3760308

3

Retainer

6

1001112496

3

Thumbscrew

7

3960447

63 in/1.6m Seal

8

4711500

2

Flatwasher 5/16in Thin

9

1001107751

1

Cover, Contactor

10

1001108251

1

Cover, Rear Axle

11

3960389

2 ft/.6m

Seal
