SECTION 8 - DECALS
154
E300AJ/E300AJP
3121254
FIGURE 8-3. DECAL INSTALLATION (AUSTRALIAN/CE SPECS)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
STANDARD DECAL INSTALLATIONS
1001110824
Ref
Australian and CE Specs
D
1001110613
Ref
Standard Decal Installations E300AJ JLG Logo Decals
B
1001115980
Ref
Standard Decal Installations E300AJP JLG Logo Decals
B
1
0641406
4
Bolt 1/4in-20NC x 3/4in
2
0641408
1
Bolt 1/4in-20NC x 1in
3
0860520
1
Box, Manual Storage
4
1060279
1
Cable, Lanyard
5
Ref
Decal - Patent Options:
5
1700584
1
Decal - Patent (SN 0300138358 through 0300161219)
5
Not Required
1
Decal - Patent (SN 0300161220 to Present)
6
1701500
4
Decal - Lift
7
1701504
1
Decal - Hydraulic Oil
8
1701509
1
Decal - Manual
9
1701529
3
Decal - Arrow 12in
10
1701642
1
Decal - Arrow 9in
11
1701644
1
Decal - Battery Charger
12
1705978
1
Decal - Capacity
13
1702155
2
Decal - Battery Disconnect
14
1702300
4
Decal - Tie Down
15
1701517
1
Decal - Hand Crushing
16
See Note
1
Decal - Bar Code (Note: Not available for purchase)
17
Ref
Decal Options:
17
1702773
1
Decal JLG (E300AJ)
17
1704200
1
Decal Jib Plus (E300AJP)
18
1702774
1
Decal - JLG Lift 3in
19
1702860
1
Decal - JLG Lift 5in
21
1705921
1
Decal - Tipping/Electrocution
22
1705822
1
Decal - Electrocution/Safety Manual
23
1701518
4
Decal - Crushing
24
1705961
3
Decal - Electrocution
25
1705670
3
Decal - Fire Hazard
26
Ref
Decal - Model Designation
26
1704199
2
Decal E300AJ
26
1704267
2
Decal E300AJP
27
1704277
2
Decal - Lanyard Attach Graphic
28
1704412
1
Decal - Hydraulic Oil
29
1704885
AR
Decal - Website Options:
29
Ref
Decal (SN 0300138358 through 0300173651)
29
Ref
Decal (SN 0300173652 to Present)
30
1706126
4
Decal - Tire Load
31
See Note
1
Nameplate - Serial Number (Note: Not available for purchase)
35
3311405
1
Locknut 1/4in-20NC
36
3820001
2
Rivet
37
4751400
6
Flatwasher 1/4in Regular
38
1001110196
1
Decal - Manual Descent
41
1001112461
1
Decal - Lift Diagram
42
1001112777
1
Decal - Manual Descent
44
1705828
1
Nameplate - Footswitch
46
4420051
11.5
Tape, Safety
