SECTION 5 - CYLINDER
3121254 E300AJ/E300AJP 105
FIGURE 5-1. LEVEL (PLATFORM SLAVE) CYLINDER ASSEMBLY
ITEM PART NUMBER QTY DESCRIPTION REV
1001105153 Ref LEVEL (PLATFORM LEVEL) CYLINDER ASSEMBLY E
1 70002361 1 Barrel Weldment
2 70002360 1 Rod Weldment
3 70002359 1 Head
4 70002350 1 Wiper
5 70002366 1 Ring, Retaining
6 70002350 1 Seal, Rod
7 70002350 1 Ring, Back-up
8 70002352 1 Ring, Wear
9 70002350 1 O-Ring
10 70002350 1 Ring, Back-up
11 70002350 1 O-Ring
12 70002358 1 Piston
13 70002350 1 Seal, Piston
14 70002350 1 O-Ring
15 70002335 1 Nut
15 0100071 AR Compound, Locking
16 70002333 4 Bearing
17 70002413 1 Cartridge, Valve (Counterbalance)
17 2900770 1 Seal Kit - 70002413 Valve (1 Per Assembly)
18 70002388 1 Cartridge, Valve (Counterbalance)
18 2900770 1 Seal Kit - 70002388 Valve (1 Per Assembly)
19 See Note 2 Plug, O-Ring(Note: Not available for purchase)
21 70002357 1 Valve, Phase
100 70002350 1 Seal Kit (Includes Items 4, 6, 7, 9, 10, 11, 13 & 14)
