SECTION 9 - RECOMMENDED SERVICE PARTS STOCK
160
E300AJ/E300AJP
3121254
FIGURE 9-2. MODELS E300AJ AND E300AJP VARIABLE PARTS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Note
1
Note: The following list will service one machine (built to
current production per date on the front cover) with emergency
repair parts which can be installed in the field. Parts from the
list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact
your JLG dealer or the JLG Industries Parts Department.
Ref
VARIABLE PARTS
1600293
1
Module, Drive
2400062
1
Fuse 300Amp (UL Spec Only)
1001112779
1
Module, Power
1001109497
1
Module, Ground Control
4360469
1
Switch, Key (All Specs Except CE Spec)
4360470
1
Switch, Key (CE Spec Only)
2940074
1
Latch (Platform with Gate)
1001117172
1
Footswitch
1001109498
1
Module, Platform
4360548
1
Switch, Limit
2400068
2
Fuse 10 Amp (Machines with Platform Worklights)
1001109475
1
Breaker, Circuit 16Amp (CE Machines with AC Power at Platform)
1001109482
1
Breaker, Circuit 30mAmp (CE Machines with AC Power at Platform)
