Chapter 2 – Specifications
4
TB65J – 0084248
General Specifications
Aerial Platform
Working height
7′ (2.6 m)
Maximum platform height
65′ (9.8 m)
Horizontal reach
56′ (7. m)
Main boom
Articulation
-6° to +72°
Extension
0 to 27′ 4″ (0 to 8.33 m)
Jib
Articulation
-70° to +70°
Extension
5′ (.5 m)
Turntable rotation
360° continuous
Turning radius, inside
5′ 5″ (4.7m)
Wheelbase
0′ (3 m)
Ground clearance
3″ (33 cm)
Maximum wheel load
2,500 lbs (5,670 kg)
Maximum ground pressure
75 psi (57 kPa)
Weight, EVW
Approximate
25,000 lbs (,340 kg)
Stowed width
7′ .5″ (2.4 m)
Stowed length
33′ (0 m)
Stowed height
8′ 9″ (2.7 m)
Platform
Dimensions
Standard steel
36″ x 96″ (9 cm x 244 cm)
Rated work load
500 lbs (227 kg)
Optional aluminum
30″ x 96″ (76 cm x 244 cm)
Rated work load
500 lbs (227 kg)
Rotation
70° CW to 80° CCW
Maximum number of occupants
2 people
Optional AC generator
0 V, 2,000 W
Optional AC generator
220 V, 3-phase, 2 kw
Optional Welder
Function Speed
Turntable rotation, 360 degrees 65 to 75 seconds
Main boom
Up
64 to 75 seconds
Down
64 to 75 seconds
Extend
65 to 75 seconds
Retract
35 to 45 seconds
Jib
Up
7 to 3 seconds
Down
7 to 3 seconds
Platform rotation, 50 degrees
6 to 20 seconds
Drive
High, booms stowed
3.0 mph (4.8 km/h)
Low, booms raised/extended
0.6 mph (0.96 km/h)
Drive System
Standard
Four wheel drive
Gradeability – theoretical 4x4
78%
Tires
Foam Filled, 2 ply
5″ x 9.5″ (38 cm x 50 cm)
Electrical System
Voltage
2 V DC negative chassis ground
Source
Two - 2 V 550 CCA batteries
Fluid recommended
distilled water
Hydraulic System
Maximum pressure
2,500 psi (7,250 kPa)
Reservoir capacity
26. US gal (99 l)
System capacity
35 US gal (32 l)
Maximum operating temperature
200°F (93°C)
Hydraulic fluid recommended
Above 0°F (-3°C)
Mobil DTE-3M (ISO VG32)
Below 0°F (-3°C)
Mobil DTE-M (ISO VG5)
Engine
Diesel
Cummins B3.3
Diesel
Deutz F4L-20F
Gasoline and/or LP
General Motors 2.4
Fuel Tank Capacity
Gasoline or diesel
40 US gal (5 l)
LPG
43.5 lbs (9.7 kg)
Dual fuel
Gasoline
40 US gal (5 l)
LPG
43.5 lbs (9.7 kg)
Ambient Air Temperature Operating Range
Fahrenheit
0°F to 0°F
Celsius
-8°C to 43°C
Maximum Wind Speed
Gust or steady
28 mph (45 km/h)
