Chapter 2 – Specifi cations
4 S2633 – 8210048
General Specifi cations
Aerial Platform
Working height 32.5 ′ (9.93 m)
Maximum platform height 26 ′ (7.93 m)
Minimum working height 43 ′ (1.09 m)
Turning radius
Inside 8 ″ (203 mm)
Wheelbase 74.75 ″ (1.9 m)
Ground clearance
Pothole protector raised 3.5″ (89 mm)
Pothole protector lowered 3.35″ (85 mm)
Maximum wheel load 1,800 lbs (818 kg)
Maximum ground pressure 137 psi (9.6 kg/cm 2 )
Empty vehicle weight (EVW)
Approximate 5,200 lbs (2358 kg)
Width 32.5 ″ (0.82 m)
Stowed height 86 ″ (2.19 m)
Rails lowered 78.25 ″ (1.99 m)
Stowed length
Extension in 92.5 ″ (2.35 m)
Extension out 128.5 ″ (3.26 m)
Maximum Chassis Inclination
Side-to-side 1.5 degrees
Front-to-rear 2.5 degrees
Platform
Dimensions
Extension in 28 ″ x 87″ (.71 m x 2.21 m)
Extension out 28 ″ x 126″ (.71 m x 3.20 m)
Guardrail height 42.25 ″ (1.1 m)
Toeboard height 6 ″ (152 mm)
Rated work load
Total 750 lbs (340 kg)
On extension 250 lbs (110 kg)
Maximum number of occupants
Total 3 people
On extension 1 person
Function Speed
Platform raise 42 seconds
Platform lower 40 seconds
Drive speed
High, platform lowered 0.50 mph (0.8 km/h)
Low, platform raised 2.0 mph (3.2 km/h)
Drive System
Standard Two wheel drive
Gradeability 26% (14.5°)
Maximum drive height 26 ′ (7.93 m)
Parking brake Dual spring applied
hydraulic release
Tires
Non-marking, solid rubber 15″ (381 mm) diameter
Electrical System
Voltage 24 V DC
Source Four - 6V 235 Ah batteries
Fluid recommended Distilled water
Battery charger 25 A, 110/220 VAC
Minimum battery weight 66 lb (30 kg)
DC electric motor 4 hp
Hydraulic System
Maximum pressure 3,000 psi (20,700 kPa)
Reservoir capacity 4 US gal (15 l)
Maximum operating temperature 200°F (93°C)
Minimum operating temperature -20°F (-28°C)
Hydraulic fl uid recommended
Above 10°F (-13°C) Mobil DTE-13M (ISO VG32)
Below 10°F (-13°C) Mobil DTE-11M (ISO VG15)
Ambient Air Temperature Operating Range
Fahrenheit 0°F to 110°F
Celsius -18°C to 43°C
Maximum Wind Speed
Gust or steady 28 mph (45 km/h)
