Chapter 11 – Emergency Operation
44 S2633 – 8210048
4. Using a 5 mm Allen wrench, turn the inner plugs as far
as possible turning clockwise (refer to Figure 11.3).
Turn the plugs alternately in ½ turn increments to
insure uniform adjustment and prevent binding.
5. Do not exceed .67 mph (1.08 km/h) when towing.
A
Warning
The aerial platform is free to move when the brakes
are released. Death or serious injury could result.
Re-enable the brakes before operating the aerial
platform.
y
6. After moving the aerial platform, using a 5 mm Allen
wrench turn the inner plugs as far as possible coun-
terclockwise and the outer plugs as far as possible
clockwise and replace the thread protector (refer to
Figure 11.3).
Turn the plugs alternately in ½ turn increments to
insure uniform adjustment and prevent binding.
7. After unloading the aerial platform from the transport
vehicle, verify that the drive system and brakes oper-
ate properly before operating the aerial platform.
