Operation Manual Page 19
Specifications
S
PECIFICATIONS
Nominal working height 10.28m 33' 9”
Roll out deck size 1200mm 48”
Drive speed (below 2.4m) 0 to 4.5kph 0 to 2.8mph
Drive speed (above 2.4m) 0 to 0.9kph 0 to 0.6mph
Safe working load - Main deck
(Roll out deck not extended) 580kg 1280lbs
Safe working load - Main deck
Roll out deck extended - Roll out deck 460kg
120kg 1015lbs
265lbs
Platform size 2.73 x 1.65m 8’ 11” x 5’ 5”
Stowed height 2.5m 8' 2"
Stowed height (hand rails folded down) 1.7m 5' 8"
Overall length 3.36m 11’ 0”
Overall width 1.7m 5' 8"
Gradeability 35%
Lift time 26 seconds
Turning radius (inner) 2.83m 9’ 3”
Turning radius (outer) 4.6m 15’ 1”
Maximum wind speed (12.5m/s) 45km/h 28mph
Insulation rating Nil
Tyres - Poly filled loader lug 27" x 10.5" x 15"
Overall weight 2800kg 6272lbs
Ground clearance 350mm 13.8”
Maximum sound level at platform 86db
Nominal working height 12.12m 39' 2”
Roll out deck size 1200mm 48”
Drive speed (below 2.4m) 0 to 4.5kph 0 to 2.8mph
Drive speed (above 2.4m) 0 to 0.35kph 0 to 0.22mph
Safe working load - Main deck
(Roll out deck not extended) 450kg 990lbs
Safe working load - Main deck
Roll out deck extended - Roll out deck 330kg
120kg 726lbs
264lbs
Platform size 2.73 x 1.65m 8’ 11” x 5’ 5”
Stowed height 2.7m 8' 10"
Stowed height (hand rails folded down) 2.0m 6' 6"
Overall length 3.36m 11’ 0”
Overall width 1.77m 5' 9"
Gradeability 35%
Lift time 50 seconds
Turning radius (inner) 2.38m 7’ 8”
Turning radius (outer) 4.75m 15’ 6”
Maximum wind speed (12.5m/s) 45km/h 28mph
Insulation rating Nil
Tyres - Poly filled loader lug 27" x 10.5" x 15"
Overall weight 3620kg 7964lbs
Ground clearance 350mm 13.8”
Maximum sound level at platform 86db
X 27-RT
X-33-RT
Spec i fi ca tions are sub ject to change with out no tice. Hot weather or heavy use may af fect per for mance. Re fer to the Ser vice Man ual for com plete
parts and ser vice in for ma tion. This ma chine meets or ex ceeds all ap pli ca ble re quire ments of OSHA and ANSI A92.6
