1. Park the work platform on firm level ground and
leave the engine running.
2. Ensure the Ground Emergency Stop Button is
pulled to the ON position.
3. Using the Ground Controls raise the scissor arm
assembly sufficiently to raise the Scissor Prop to
a vertical position.
4. Using the Ground Controls lower the scissor
arm assembly until it is firmly resting on the
prop.
1. Using the Ground Controls raise the scissor arm assembly until the safety prop can be
removed.
2. Place the scissor arm prop back into it's cradle.
3. Lower the scissor arm assembly until it reaches its stowed position.
Page 14 Operation Manual
Maintenance
M
AINTENANCE
W A R N I N G
Never per form ser vice while the plat form is el e vated with out first block ing the el e vat ing as -
sem bly.
DO NOT stand in the el e vat ing as sem bly area while de ploy ing or stor ing the brace.
Figure 7: Scissor Brace
B
LOCKING THE
E
LEVATING
A
SSEMBLY
I
NSTALLATION
R
EMOVAL
