Snorkel X33RT-sn10000+ - Manual (Page 15)

1. Undo the cables from the control box and remove the two "grip clips". Remove the control box
and store it securely.
2. Pull out the two pins at the base of the front guardrail and lift it out of the 2 locking clevis
fixtures at the top on each side.
3. Lay the front guardrail on the deck of the platform.
4. Repeat steps 2 and 3 for the rear guardrail.
5. Working with either side guardrail, remove the two pins from the extension deck guardrail and
fold it over onto the deck. Repeat this for the extension guardrail on the other side.
6. Remove the 4 pins from one of the side guardrails and fold this down on to the deck. Repeat
the procedure for the other side.
1. Raise the side guardrails and insert locking pins.
2. Raise the extension deck guardrails and insert the locking pins.
3. Lift the rear guardrail into position aligning the two clevis fixtures and pull/push it securely into
place. Insert the two locking pins.
4. Repeat step 3 for the front guardrail.
5. Reattach the control box with the two "grip clips" and reattach the control cables.
Operation Manual Page 11
Operation
F
OLD
D
OWN
G
UARDRAILS
NOTE: Guard rails must be re turned to proper po si tion be fore us ing the ma chine.
F
OLD
D
OWN
P
ROCEDURE
E
RECTION
P
ROCEDURE
D A N G E R
Be fore en ter ing the plat form, guard -
rails must be se
curely fas tened in
their proper po si tion.
