1. At the ground control box set the Emergency Stop switch to off, turn the Main Power switch
to off and remove the key.
2. Inside the Hydraulic Compartment, open the Free-Wheeling Valve by turning
counterclockwise until the knob stops.
3. To Release the Brakes, Pump the Hand-Pump 5-10 times. The brakes will now be released
and the machine is ready to be towed, pushed, or winched.
4. Once the machine has been safely towed pull the Re-set Knob to re-apply the brakes, and
close the Free-Wheel Valve by turning fully clockwise.
1. Ensure that the platform is fully lowered and that all four stabilisers are fully retracted.
2. Park the machine on a firm level surface, preferably under cover, secure against vandals,
children and unauthorized operation.
3. Turn the Battery Switch to OFF and padlock it.
4. Turn the Ground Key Switch to OFF and remove the Key to prevent unauthorized
operation.
Page 12 Operation Manual
Towing or Winching
T
OWING OR
W
INCHING
Per form the fol low ing only when the ma chine will not op er ate un der its own power and it is nec es -
sary to move the ma chine or when winch ing onto a trans port ve hi cle (see "Trans port ing the Work
Plat form" on page 13).
C A U T I O N
DO NOT tow or winch the ma chine faster than 2 mph (3.2 km/hr), (0.9m/s), (3ft./s). Faster
speeds will dam age drive com po nents and void the war ranty.
B
RAKE
R
ELEASE
P
UMP
Per form the fol low ing only when the ma chine will not op er ate un der it's own power and it is nec es -
sary to move the ma chine or when tow ing the ma chine up a grade or onto a trailer to trans port.
FREE-WHEEL
VALVE
HAND
PUMP
RE-SET
KNOB
Figure 5: Brake Release Pump
W A R N I N G
Never tow faster than 0.9 m/sec (3 ft./sec.).
Never op er ate the work plat form with the park ing brakes re leased. Se ri ous in jury or dam age
could re sult.
A
FTER
U
SE
E
ACH
D
AY
H
OUR
M
ETER
The hour me ter can be read from the Ground Con trol Box.
