Snorkel ULII40-sn15001-21372 - Manual (Page 15)

2
English
Language
Section
SAFETY RULES
NEVER
attempt
to
move
the
UpRight
Lift
with
people
or
materials
on
the
platform
or
with
the
platform
elevated.
NEVER
elevate
platform
unless
all
four
(4)
outriggers have
been
properly
installed.
All
outrigger
screwjack
pads
must
be
in
solid
contact
with
a
firm
surface
before
the
platform
is
elevated.
NEVER
operate
the
machine
within
ten
feet
of
power
lines.
THIS
MACHINE
IS
NOT
INSULATED
.
NEVER
sit,
climb,
or
stand
on
the
platform
guardrails
or
midrail.
NEVER
elevate
platform
without
first
leveling
the
base.
NEVER
use
ladders,
planks
or
other
devices
to
increase
the
height
of
the
platform.
NEVER
attach
overhanging
loads
to
the
platform
or
increase
the
platform
size.
NEVER
elevate
the
platform
if
it
contains
more
than
one
person
or
more
than
the
rated
load
(see
specifica-
tions
on
back
page).
LOOK
up,
down
and
around
for
overhead
obstructions
and
electrical
conductors.
NEVER
change
operating
or
safety
systems.
NEVER
use
outriggers
from
one
model
on
another
model.
CLOSE
and
secure
cage
after
entering
platform.
INSPECT
the
machine
thoroughly
for
cracked
welds,
loose
or
missing
hardware,
hydraulic
leaks,
dam-
aged
control
or
power
cables
and
loose
wire
connections.
NEVER
use
the
machine
as
a
freight
or
personnel
elevator.
NEVER
recharge
battery
near
sparks
or
open
flame;
batteries
that
are
being
charged
emit
highly
explosive
hydrogen
gas.
AFTER
USE
, secure
the
work
platform
against
unauthorized
use
by
turning
key
switch
off
and
removing
key. NEVER
replace
any
component
or
part
with
anything
other
than
original
UpRight
replacement
parts
without
the
manufacturer's
consent.
31
ULII
Hydraulic
Schematic
- 068011-000
ENGLISH
FRANCAIS
GERMAN
SPANISH
1
Valve
Vanne
Ventil
Válvula
2
Relief
valve
Clapet de décharge
Überdruckventil
Válvula
de
alivio
3
Cylinder
Vérin
Zylinder
Cilindro
4
Check
valve
Clapet de non-retour
Rückschlagventil
Válvula de retención
5
Orifice
Orifice
Drosselblende
Orificio
6
Pump
Pompe
Pumpe
Bomba
7
Filter
Filtre
Filter
Filtro
