Page 22 Operator Manual
067903-025 LX31/LX41/LX50 Specifications
S PECIFICATIONS
Specifications subject to change without notice. Refer to the Service Manual for service and repair infor-
mation. Refer to the Parts Manual for illustrated parts breakdown. Hot weather or heavy use may reduce
performance. Meets or exceeds all applicable national safety requirements
ITEM LX31 LX41 LX50
Platform Size (Inside toeboards)
Standard 3,96 m x 1,73 m [156 in x 68 in.] 3,96 m x 1,73 m [156 in x 68 in.] 3,96 m x 1,73 m [156 in x 68 in.]
Slide-out Deck Extended 4,83 m x 1,73 [190 in. x 68 in.] 4,83 m x 1,73 [190 in. x 68 in.] 4,83 m x 1,73 [190 in. x 68 in.]
Max. Platform Capacity
Standard 907 kg [2,000 lbs.] 680 kg [1,500 lbs.] 454 kg [1,000 lbs.]
With Rear Deck Option 794 kg [1750 lbs.] 567 kg [1,250 lbs.] 341 kg [750 lbs.]
On Extension 227 kg [500 lbs.] 227 kg [500 lbs.] 227 kg [500 lbs.]
Max. No. of occupants
Standard 5 people 5 people 4 people
With Rear Deck Option 5 people 4 people 3 people
Height
Working Height 11,45 m [37 ft. 6 in.] 14,34 m [47 ft. 3 in.] 17,1 m [56 ft.]
Max. Platform Height 9,45 m [31 ft.] 12,34 m [40 ft. 6 in.] 15,1 m [49 ft. 6 in.]
Min. Platform Height 1,43 m [56.3 in.] 1,66 m [65.3 in.] 1,9 m [76 in.]
Drivable Height 8 m [26 ft. 3 in.] 8 m [26 ft. 3 in.] 8 m [26 ft. 3 in.]
Dimensions
Weight, Standard 2WD:
4WD: 4314 kg [9,511 lbs.]
4436 kg [9,780 lbs.] 5026 kg [11,080 lbs.]
5148kg [11,349 lbs.]
6242 kg [13,761 lbs.]
6364 kg [14,030 lbs.]
Weight, Dual Deck 2WD:
4WD: 4645 kg [10,241 lbs.]
4767 kg [10,440 lbs.] 5357 kg [11,810 lbs.]
5479 kg [12,079 lbs.] 6460 kg [14,242 lbs.]
6583 kg [14,513 lbs.]
Overall Width 2,29 m [90 in.] 2,29 m [90 in.] 2,29 m [90 in.]
Overall Height, guardrails up 2,53 m [99.8 in.] 2,76 m [109 in.] 3 m [118.3 in.]
Overall Height, guardrails lowered 1,64 m [64.5 in.] 1,87 m [73.5 in.] 2,1 m [82.5 in.]
Overall Length, deck in 4,02 m [160 in.] 4,02 m [160 in.] 4,02 m [160 in.]
Overall Length, deck extended 4,89 m [192 in.] 4,89 m [192 in.] 4,89 m [192 in.]
Surface Speed
Platform Lowered 0 to 5,0 km/h [0 to 3.1 mph] 0 to 5,0 km/h [0 to 3.1 mph] 0 to 5,0 km/h [0 to 3.1 mph]
Platform Raised 0 to 0,48 km/h [0 to 0.5 mph] 0 to 0,48 km/h [0 to 0.5 mph] 0 to 0,48 km/h [0 to 0.5 mph]
System Voltage 12 Volt DC 12 Volt DC 12 Volt DC
Hydraulic Tank Capacity 107 liters [28.3 US Gallons] 107 liters [28.3 US Gallons] 107 liters [28.3 US Gallons]
Maximum Hydraulic System Pressure 207 bar [3000 psi] 207 bar [3000 psi] 207 bar [3000 psi]
Hydraulic Fluid
Normal Temperature: above 0° C [32° F] ISO #46 ISO #46 ISO #46
Low Temperature: below 0° C [32° F] ISO #32 ISO #32 ISO #32
Extreme Temperature: below -17° C [0° F] ISO #15 ISO #15 ISO #15
Lift System One Single Stage Lift Cylinder One Single Stage Lift Cylinder Two Single Stage Lift Cylinders
Lift Speed Raise: 40 sec. Lower: 52 sec. Raise: 45 sec. Lower: 60 sec. Raise: 80 sec. Lower: 112 sec.
Power Source Diesel 20 HP Kubota, 3 Cylinder,
Water Cooled
Diesel 20 HP Kubota, 3 Cylinder,
Water Cooled
Diesel or HP Kubota, 3 Cylinder, Water Cooled
Drive Control Proportional Proportional Proportional
Control System Smooth one-hand Joystick Smooth one-hand Joystick Smooth one-hand Joystick
Horizontal Drive 2WD:
4WD: 2 Wheel, Hyd. Motors
4 Wheel, Hyd. Motors 2 Wheel, Hyd. Motors
4 Wheel, Hyd. Motors 2 Wheel, Hyd. Motors
4 Wheel, Hyd. Motors
Tires 10-16.5 NHS 8 Ply 10-16.5 NHS 8 Ply 10-16.5 NHS 8 Ply Poly Filled
Tire Air Pressure 3,4 bar [50psi.] 3,4 bar [50psi.] NA
Parking Brakes Dual Disc, Spring Applied,
Hydraulic Release
Dual Disc, Spring Applied,
Hydraulic Release
Dual Disc, Spring Applied, Hydraulic Release
Turning Radius (inside) 1,22 m [48 in.] 1,22 m [48 in.] 1,22 m [48 in.]
Maximum Gradeability: 2WD:
4WD: 17° [30%]
19° [35%] 17° [30%]
19° [35%] 13,5° [24%]
13,5° [24%]
Wheel Base 2WD:
4WD: 2,9 m [114.5 in.]
2,95 m [116 in.]
2,9 m [114.5 in.]
2,95 m [116 in.]
2,9 m [114.5 in.]
2,95 m [116 in.]
Ground Clearance 0,24 m [9.5 in.] 0,24 m [9.5 in.] 0,24 m [9.5 in.]
Guardrails 1.1 m [43.5 in.] high,
Fold Down with gate.
1.1 m [43.5 in.] high,
Fold Down with gate.
1.1 m [43.5 in.] high,
Fold Down with gate.
Noise Level
