Operation 067903-025 LX31/LX41/LX50
Operator Manual Page 11
E M E R G E N C Y L O W E R I N G
LX31 AND LX41
Figure 4: Emergency Lowering Valve, LX31 and LX41
The emergency lowering control knob is located at the
rear of the machine at the base of the scissor assembly.
1. Open the emergency lowering valve by pulling on the
knob and holding it.
2. Once the platform is fully lowered, release the knob to
close the valve.
LX50
Figure 5: Emergency Lowering, LX50
The emergency lowering control switch is located at the rear of the
machine at the base of the scissor assembly.
1. Open the emergency lowering valve by pushing down on the tog-
gle switch and holding it.
2. Once the platform is fully lowered, release the toggle switch to
close the valve.
