Micropump GN Series Installation, Operation and Warranty Information - Manual (Page 34)

34
DOC No: 7046 REV G
SERIES PF
Flow Rate @1000 rpm 0.94 l/min (0.248 gpm)
Max. Speed 1000 rpm
Max. System Pressure 6.89 bar (100 psi)
Max. Differential Pressure
(Continuous Duty) 6.89 bar (100 psi)
Max. Differential Pressure
(Intermittent Duty) 6.89 bar (100 psi)
Max. Differential Pressure
(Blocked Outlet) 6.89 bar (100 psi)
Max. De-Coupling Torque N/A
Viscosity Range 100 to 5000 centipoise
Fluid Temperature Range -46 to +121°C (-51 to +249.8°F)
Bypass Valve Not Available
Noise Level Less than 70 dbA
Weight 2.0 kg (4.4 lbs)
