29
DOC No: 7046 REV G
SERIES GK
K23 GEARS
Flow Rate @3450 rpm
Flow Rate @2850 rpm 10.9 l/min (2.9 gpm)
9.0 l/min (2.4 gpm)
Max. Speed 4000 rpm
Max. System Pressure 21 bar (304.6 psi) D-mount / 69 bar (1000.8 psi) 12-mount /103 bar (1493.9) All Other Mounts
Max. Differential Pressure
(Continuous Duty) 3.5 bar (50.8 psi)
Max. Differential Pressure
(Intermittent Duty) 3.5 bar (50.8 psi)
Max. Differential Pressure
(Blocked Outlet) 4.2 bar (60.9 psi)
Max. De-Coupling Torque 417 mN*m (3.7 in*lbs)
Viscosity Range 0.2 to 1500 centipoise
Fluid Temperature Range -46 to +54°C (-51 to +129.2°F)
Bypass Valve Not Available
Noise Level Less than 70 dbA
Weight 1.63 kg (3.6 lbs)
