26
DOC No: 7046 REV G
SERIES GC
M23 GEARS M25 GEARS M35 GEARS
Flow Rate @3450 rpm
Flow Rate @2850 rpm 2.8 l/min (0.74 gpm)
2.3 l/min (0.61 gpm) 6.4 l/min (1.7 gpm)
5.2 l/min (1.4 gpm) 12.0 l/min (3.2 gpm)
10.0 l/min (2.6 gpm)
Max. Speed 6000 rpm 4000 rpm 4000 rpm
Max. System Pressure 69 bar (913.7 psi) F or 12-mount / 103 bar (1493.9) All Other Mounts
Max. Differential Pressure
(Continuous Duty) 5.2 bar (75.4 psi) PPS GEARS / 8.7 bar (126.2 psi) PEEK GEARS
Max. Differential Pressure
(Intermittent Duty) 5.2 bar (75.4 psi) PPS GEARS / 8.7 bar (126.2 psi) PEEK GEARS
Max. Differential Pressure
(Blocked Outlet) 8.7 bar (126.2 psi)
Max. De-Coupling Torque 643 mN*m (5.7 in*lbs) standard / 1780 mN*m (15.8 in*lbs) Rare Earth
Viscosity Range 0.2 to 1500 centipoise
Fluid Temperature Range -46 to +177°C (-51 to +351°F)
Bypass Valve Not Available
Noise Level Less than 70 dbA
Weight 1.63 kg (3.6 lbs)
