32
DOC No: 7046 REV G
SERIES GN
G35 GEARS
Flow Rate @3450 rpm
Flow Rate @2850 rpm 84.8 l/min (22.4 gpm) / 69.9 l/min (18.5 gpm)
Max. Speed 1750 rpm
Max. System Pressure 21 bar (304.6 psi) standard / 69 bar (1000.8 psi) CH10 / 103 bar (1493.9) CH15
Max. Differential Pressure (Continuous Duty) 3.5 bar (50.8 psi) PTFE GEARS
8.7 bar (126.2 psi) PEEK GEARS
Max. Differential Pressure (Intermittent Duty) 3.5 bar (50.8 psi) PTFE GEARS
8.7 bar (126.2 psi) PEEK GEARS
Max. Differential Pressure (Blocked Outlet) 8.7 bar (126.2 psi) PEEK GEARS
Max. De-Coupling Torque 5650 mN*m (50.0 in*lbs)
Viscosity Range 0.2 to 2500 centipoise
Fluid Temperature Range -46 to +121°C (-51 to +249.8°F)
Bypass Valve Not Available
Noise Level Less than 70 dbA
Weight 8.4 kg (18.5 lbs)
