Micropump GN Series Installation, Operation and Warranty Information - Manual (Page 33)

33
DOC No: 7046 REV G
SERIES PD
ID-160 ID-200
Flow Rate @300 rpm 49.0 ml/min (0.78 gph) 60.0 ml/min (0.95 gph)
Max. Speed 300 rpm
Max. System Pressure 7 bar (101.5 psi)
Max. Differential Pressure
(Continuous Duty) 7 bar (101.5 psi)
Max. Differential Pressure
(Intermittent Duty) 7 bar (101.5 psi)
Max. Differential Pressure
(Blocked Outlet) 7 bar (101.5 psi)
Max. De-Coupling Torque N/A
Viscosity Range 0.5 to 100 centipoise
Fluid Temperature Range -0 to +55°C (+32 to +130°F)
Bypass Valve Not Available
Noise Level Less than 70 dbA
Weight 1.0 kg (2.2 lbs)
