20
DOC No: 7046 REV G
All Dimensions in mm.[inch]
Technical Specification
Not all mounting configurations are shown. Contact your local Micropump
distributor or contact Micropump directly for additional versions.
Pump and drive dimensions may be summed to determine total unit
dimensions.
SERIES CA
Flow Rate @3450/2850 rpm 9.8 l/min (2.6 gpm) / 8.1 l/min (2.1 gpm)
Max. Speed 10000 rpm
Max. System Pressure 13.6 bar (197.3 psi)
Max. Differential Pressure (Continuous Duty) 1.5 bar (21.8 psi)
Max. Differential Pressure (Intermittent Duty) 1.5 bar (21.8 psi)
Max. Differential Pressure (Blocked Outlet) 1.5 bar (21.8 psi)
Viscosity Range Up to 100 -
Fluid Temperature Range -46 to +122°C (-51 to +252°F)
Bypass Valve Not Available
Noise Level Less than 70 dbA
Weight 0.37 kg (.82 lbs)
CA SERIES on A MOUNT
Operating temperature range of some configurations and material
selections may be more narrow than those listed. Contact your local
Micropump distributor or contact Micropump directly for information.
CAUTION
NOTE
NOTE
NOTE
