30
DOC No: 7046 REV G
SERIES GL
H21 GEARS H23 GEARS H25 GEARS
Flow Rate @3450 rpm
Flow Rate @2850 rpm 15.9 l/min (4.2 gpm)
13.2 l/min (3.5 gpm) 21.6 l/min (5.7 gpm)
17.7 l/min (4.7 gpm) 26.9 l/min (7.1 gpm)
22.0 l/min (5.8 gpm)
Max. Speed 3450 rpm
Max. System Pressure 21 bar (304.6 psi) standard / 103 bar (1493.9) CH15 / 345 bar (5003.8 psi) CH50
Max. Differential Pressure
(Continuous Duty) 3.5 bar (50.8 psi) PTFE GEARS / 8.7 bar (126.2 psi) PEEK GEARS
Max. Differential Pressure
(Intermittent Duty) 3.5 bar (50.8 psi) PTFE GEARS / 8.7 bar (126.2 psi) PEEK GEARS
Max. Differential Pressure
(Blocked Outlet) 8.7 bar (126.2 psi) PEEK GEARS
Max. De-Coupling Torque 634 mN*m (5.6 in*lbs) standard / 3298 mN*m (29.2 in*lbs) Rare Earth
Viscosity Range 0.2 to 2500 centipoise
Fluid Temperature Range -46 to +121°C (-51 to +249.8°F)
Bypass Valve Not Available
Noise Level Less than 70 dbA
Weight 3.9 kg (8.6 lbs)
