31
DOC No: 7046 REV G
SERIES GM
G21 GEARS G23 GEARS G25 GEARS
Flow Rate @3450 rpm
Flow Rate @2850 rpm 25.4 l/min (6.7 gpm)
20.9 l/min (5.5 gpm) 34.1 l/min (9.0 gpm)
28.0 l/min (7.4 gpm) 42.4 l/min (11.2 gpm)
34.8 l/min (9.2 gpm)
Max. Speed 1750 rpm
Max. System Pressure 41 bar (594.7 psi) standard / 103 bar (1493.9) CH15
Max. Differential Pressure
(Continuous Duty) 3.5 bar (50.8 psi) PTFE GEARS / 8.7 bar (126.2 psi) PEEK GEARS
Max. Differential Pressure
(Intermittent Duty) 3.5 bar (50.8 psi) PTFE GEARS / 8.7 bar (126.2 psi) PEEK GEARS
Max. Differential Pressure
(Blocked Outlet) 8.7 bar (126.2 psi) PEEK GEARS
Max. De-Coupling Torque 5650 mN*m (50.0 in*lbs)
Viscosity Range 0.2 to 2500 centipoise
Fluid Temperature Range -46 to +121°C (-51 to +249.8°F)
Bypass Valve Not Available
Noise Level Less than 70 dbA
Weight 10.9 kg (23.9 lbs)
