WINCH ASSEMBLY
ITEM
PART NO.
DESCRIPTION
LH RH
1.
01279
GRIP RING, EXTERNAL
2
2
2.
01280
SOCKET HEAD SHOULDER SCREW, 3/8” x 3/8”
2
2
3.
15302
HYDRAULIC MOTOR
1
1
4.
15333
CONNECTING ROD
1
1
5.
15337
RETAINING RING, EXTERNAL
4
4
6.
15338
SPRING, COMPRESSION
1
1
7.
15348
BEARING, FLANGE
2
2
8.
15349
BEARING, FLANGE
1
1
9.
15352
KEY, 3/16” SQUARE x 1/2” LONG
1
1
10.
15367
LEVER, COATED
1
1
11.
15370
PIVOT PIN
1
1
12.
15380
PIVOT SHAFT
1
1
13.
15383
BRACKET, MOTOR SUPPORT
1
1
14.
15369
PINION - S/N 103000073 and below
1
1
16119
PINION - S/N 103000074 and above
1
1
15.
15389
BACK PLATE - S/N 103000073 and below
1
16124
BACK PLATE - S/N 103000074 and above
1
15382
BACK PLATE - S/N 103000073 and below
1
16126
BACK PLATE - S/N 103000074 and above
1
16.
15433
WINCH COVER, METAL - S/N 103000073 and below
1
15388
WINCH COVER, PLASTIC - S/N 103000074 and above
1
15432
WINCH COVER, METAL - S/N 103000073 and below
1
15379
WINCH COVER, PLASTIC - S/N 103000074 and above
1
17.
15283
WINCH - S/N 103000073 and below
1
16185
WINCH - S/N 103000074 and above
1
15358
WINCH - S/N 103000073 and below
1
16186
WINCH - S/N 103000074 and above
1
18.
15387
PINION COVER, PLASTIC
1
1
19.
F023203PMS
PAN HEAD MACHINE SCREW, #8-32 x 3/8”
2
2
20.
F02LW
LOCKWASHER, #8
2
2
21.
F02SW
WASHER, #8
2
2
22.
F033202SSS
SET SCREW, #10-32 x 1/4”
1
1
23.
F042004HCS
HEX HEAD CAP SCREW, 1/4-20 x 1/2”
2
2
24.
F0420DLN
DEFORMED LOCKNUT, 1/4-20
2
2
25.
F042806FSS
FLAT HEAD SCREW, 1/4-28 x 3/4”
5
5
26.
F0518HN
HEX NUT, 5/16-18
1
1
27.
F05BFW
BRASS WASHER, 5/16”
2
2
28.
F061607FWS
FLANGE SCREW, 3/8-16 x 7/8”
2
2
29.
F0616FN
FLANGE NUT, 3/8-16
2
2
30.
F06SW
WASHER, 3/8”
3
3
