35
5.0 HP BRIGGS & STRATTON ENGINE KIT
PART NUMBER 08855
ITEM NO PART NO DESCRIPTION QTY
1 01304 ENGINE, BRIGGS & STRATTON 135232 5.0 H.P. 1
2 06473 CLUTCH, CENTRIFUGAL 3/4 BORE 1
3 00032 KEY, 3/16 sq. X 1-5/8 1
4 F052412HCS HHCS, 5/16-24 X 1-1/2 1
5 F05LW LOCKWASHER, 5/16 1
6 01099 WASHER 1
7 09071 V-BELT, A-48 (One spare supplied) 2
8 F051812HCS HHCS, 5/16-18 X 1-1/2 4
9 F05SW PLAINWASHER, 5/16 4
10 F0518FN NUT, FLANGE WHIZ-LOCK 5/16 4
11 F061608FWS FWLS, 3/8-16 X 1 8
12 F0616FN NUT, FLANGE WHIZ-LOCK 3/8 12
13 F061620HCS HHCS, 3/8-16 X 2-1/2 4
14 F06LW LOCKWASHER, 3/8 4
15 09090 BRACKET, ENGINE MOUNTING 1
16 09087 DECK WELDMENT, ENGINE 1
17 09092 BELT GUARD 1
18 F051804FWS FWLS, 5/16-18 X 1/2 3
19 09126 SHEAVE, SINGLE GROOVE 1
20 09076 FLEX COUPLING ASM (Includes 2 # 11734 COLLARS) 1
21 11734 COLLAR, FLEX COUPLING 2
22 08808 END BRACKET 2
23 08829 EYE, TURNBUCKLE (RH) 2
24 F1216HN NUT, HEX 3/4-16 4
25 F12LW LOCKWASHER 3/4 2
26 F101818HCS HHCS 5/8-18 X 2-1/4 2
27 F10LW LOCKWASHER, 5/8 2
28 F1018HN NUT, HEX 5/8-18 2
29 08885 WALL BRACKET 1
30 F081310HCS HHCS 1/2-13 X 1-1/4 2
31 F08SW PLAINWASHER 1/2 4
32 F08LW LOCKWASHER 1/2 2
33 F0813HN NUT, HEX 1/2-13 2
