HYDRAULIC WINCH
ITEM NO PART NO DESCRIPTION QTY
1 08808 WELDMENT, BRACKET END 1
2 14722 CLEVIS, THREADED 1
3 15318 TANK, OIL, SCREED 1
4 15336 HANDLE WINCH 1
5 15345 WINCH DRIVE ASSEMBLY (L.H.) (includes item NO TAG on page NO TAG) 1
5 15359 WINCH DRIVE ASSEMBLY, (RH) 1
6 15360 BLOCK, NEEDLE AND RELIEF(reversed on RH) (see page 51 for hydraulics) 1
7 15368 BAR, EXTENSION 1
8 15403 SUPPORT, WINCH HANDLE 1
9 F042018SCS SHSS, 1/4-20 X 2-1/4" 3
10 F0420HN HEX NUT, 1/4-20 3
11 F04LW LOCKWASHER, 1/4" 3
12 F061606FWS FWLS, 3/8-16 X 3/4" 1
13 F061608HCS HHCS, 3/8-16 X 1" GR5 3
14 F0616FN FLANGE, WHIZ-LOCK, NUT 3/8-16 3
15 F06SW WASHER, 25/64 X 1 X 1/8 10
16 F101818HCS HHCS, 5/8-18 X 2-1/4" 2
17 F1018HN HEX NUT, 5/8-18 2
18 F10LW LOCKWASHER, 5/8" 2
19 F1216HJN NUT, HEX JAM, 3/4-16 2
20 F12LW LOCKWASHER, 3/4" 1
21
22
23
24
25
26
QTY IS PER SIDE
