MODEL AVS8
AVS SCREED SECTION
ACCESSORIES, KITS & ASSEMBLIES
ITEM
NO.
PART NO.
DESCRIPTION
QTY.
PART NO.
DESCRIPTION
QTY.
1
08852
TUBE, TOP 8 FT.
1
08917
KIT, HARDWARE AIR SCREED
2
F061616HCS
HHCS 3/8-16 X 2
16
Included items:
3
F06LW
LOCKWASHER, 3/8
16
(16)
2
4
F0616HN
NUT, HEX 3/8-16
16
(17)
2
5
08805
A-FRAME, LEFT (8800)
4
(18)
2
6
08806
A-FRAME, RIGHT (8801)
4
(19)
1
7
08870
GROMMET
4
(20)
1
8
08848
EDGING, STRIKE OFF 8 FT.
1
(21)
1
9
08873
EDGING, FLOAT 8 FT.
1
(22)
1
10
F061608FWS
FWLS, 3/8-16 X 1
14
(23)
1
11
F061614FWS
FWLS, 3/8-16 X 1-3/4
2
(24)
1
12
08818
NUT, BLIND
8
(25)
1
13
08902
MANIFOLD, AIR 8 FT.
1
(26)
1
14
F0227SPP
SOCKET PIPE PLUG, 1/8-27
3
(27)
1
15
08828
CLEVIS
2
16
F101818HCS
HHCS, 5/8-18 X 2-1/4
2
08914
KIT, EXCITER AIR
17
F10LW
LOCKWASHER, 5/8
2
Included Items:
18
F1018HN
NUT, HEX 5/8-18
2
(23)
1
19
08839
TURNBUCKLE
1
(28)
1
20
08830
EYE, TURNBUCKLE (LH)
1
(29)
1
21
F1216HJN-LH NUT, HEX JAM 3/4-16 (LH)
1
(30)
1
22
08829
EYE, TURNBUCKLE (RH)
1
(31)
2
23
F1216HJN
NUT, HEX JAM 3/4-16
5
(32)
2
24
08831
PLATE ASM, SPLICE, LONG
1
(33)
1
25
08832
PLATE ASM, SPLICE, SHORT
1
(34)
1
26
08838
PLATE, SPLICE
2
27
08905
HOSE, AIR
1
08992
EDGING, PLOW 8FT.
1
28
08894
EXCITER, AIR
4
(Option for item #8)
29
F12LW
LOCKWASHER 3/4
4
30
08900
BRACKET, EXCITER
4
08987
EDGING, TAMPER 8FT.
1
31
F061607FWS
FWLS, 3/8-16 X 7/8
8
(Option for item #8)
32
F0616FN
FWLN, 3/8-16
8
33
09074
HOSE, AIR
4
02535
TURNBUCKLE ASM
34
08909
CONNECTOR, MALE
4
Includes items:
(23)
1
(24)
1
(25)
1
(26)
1
(27)
1
