23
LONG STORAGE
(Mechanical Screed)
Before storing screed for an extended period of time:
1. Grease bearings with one shot of low temperature grease after final usage before storĆ
ing. Run screed at operating speed for one minute after greasing all bearings.
2. Refer to engine's OPERATORS MANUAL for instructions on storage procedure for enĆ
gine.
CHANGE HYDRAULIC OIL
(Hydraulic Winches)
1. Remove winch assembly from screed
sections.
2. Lay winch assembly on its side (rails
pointed up) and remove lower hydrauĆ
lic hose.
3. Remove filter/fitting assembly (Figure
35, items 9, 10 & 53)
4. Tip winch assembly over and drain oil
into a drain pan and dispose of properĆ
ly.
5. Clean filter assembly in a cleaning solĆ
vent, inspect filter and replace if damĆ
aged.
6. Check all hoses for wear or damage,
replace as necessary.
7. Reassemble filter assembly and hyĆ
draulic hose. Then, refill tank with 1.7
gallons of a good grade of hydraulic oil.
WINCH MAINTENANCE
(Hydraulic Winches)
1. Remove guard and inspect cable for
wear, replace if damaged.
2. Inspect all bushings for wear, replace if
damaged.
3. Inspect both drive and driven gears for
wear, replace if necessary. Make sure
gears are free of any foreign materials.
4. Reinstall guard and inspect decals, reĆ
place decals if damaged or illegible.
TORQUE CHART
TIGHTENING TORQUE CONVERSIONS
SIZE GRADE 2 GRADE5
10Ć24 32 inĆlb 40 inĆlb in lbs x 0.083 = ftĆlbs
10Ć32 32 inĆlb 32 inĆlb
1/4Ć20 70 inĆlb 115 inĆlb ft lbs x 12 = inĆlbs
1/4Ć28 85 inĆlb 140 inĆlb
5/16Ć18 150 inĆlb 250 inĆlb ft lbs x 0.1383 = kgĆm
5/16Ć24 165 inĆlb 270 inĆlb
3/8Ć16 260 inĆlb 35 ftĆlb ft lbs x 1.3558 = NDm
3/8Ć24 300 inĆlb 40 ftĆlb
7/16Ć14 35 ftĆlb 55 ftĆlb
7/16Ć20 45 ftĆlb 75 ftĆlb
1/2Ć13 50 ftĆlb 80 ftĆlb
1/2Ć20 70 ftĆlb 105 ftĆlb
