Page 38
8.0 HP HONDA ENGINE KITS
ITEM
PART NO.
DESCRIPTION
STD HD
1.
01465
ENGINE, HONDA GX240K1QA 8 H.P.
1
1
2.
06606
CLUTCH, CENTRIFUGAL 1” BORE
1
17149
CLUTCH, CENTRIFUGAL, 1” BORE, DOUBLE GROOVE
1
3.
01161
KEY, 1/4 SQUARE X 1-1/2
1
1
4.
F072012HCS
HHCS, 7/16-20 X 1-1/2
1
1
5.
F07LW
LOCKWASHER, 7/16
1
1
6.
06638
WASHER
1
1
7.
09096
V-BELT, A-49 (INCLUDES 1 SPARE BELT FOR STD KIT, 2 FOR HD)
2
4
8.
F061614HCS
HHCS, 3/8-16 X 1-3/4
4
4
9.
F06SW
WASHER, 3/8
4
4
10.
F0616FN
NUT, FLANGE WHIZ-LOCK 3/8
4
4
11.
F061608FWS
FWLS, 3/8-16 X 1
8
8
12.
F0616FN
NUT, FLANGE WHIZ-LOCK 3/8
12
12
13.
F061620HCS
HHCS, 3/8-16 X 2-1/2
4
4
14.
F06LW
LOCKWASHER, 3/8
4
4
15.
09090
BRACKET, ENGINE MOUNTING
1
1
16.
09087
DECK WELDMENT, ENGINE
1
1
17.
09092
BELT GUARD
1
1
18.
F051804FWS
FWLS, 5/16-18 X 1/2
3
3
19.
09126
SHEAVE, SINGLE GROOVE
1
16272
SHEAVE, DOUBLE GROOVE
1
20.
09076
FLEX COUPLING (INCLUDES 2 #11734 COLLARS)
1
1
21.
11734
COLLAR, FLEX COUPLING
2
2
22.
08808
END BRACKET
1
1
23.
08829
EYE, TURNBUCKLE (RH)
2
2
24.
F1216HN
NUT, HEX 3/4-16
4
4
25.
F12LW
LOCKWASHER 3/4
2
2
26.
F101818HCS
HHCS, 5/8-18 X 2-1/4
2
2
27.
F10LW
LOCKWASHER, 5/8
2
2
28.
F1018HN
NUT, HEX 5/8-18
2
2
29.
08885
WALL BRACKET
1
1
30.
F081310HCS
HHCS, 1/2-13 X 1-1/4
2
2
31.
F08SW
WASHER, 1/2
4
4
32.
F08LW
LOCKWASHER, 1/2
2
2
33.
F0813HN
NUT, HEX 1/2-13
2
2
09072
ENGINE KIT, STANDARD DRIVE (INCLUDES ITEMS 1-33)
1
16273
ENGINE KIT, HEAVY DUTY DRIVE (INCLUDES ITEMS 1-33)
1
THE 2 FOOT A-FRAME SECTION SHOWN IS NOT INCLUDED IN THESE
KITS. THIS SECTION IS ONLY SHOWN FOR ASSEMBLY PURPOSES.
