Page 33: Technical data sheet
FORM-ENG-0018 REV A 05-27-03
607 NW 27th Ave
Ocala, FL 34475
Ph: 352-629-5020 or 1-800-533-3569
Fax : 352-629-2902 or 1-800-520-3473
TECHNICAL DATA SHEET
PAGE
32
OF 36
DATE
6/19/2014
PRODUCT GROUP
THROTTLE CONTROL
P/N
3045-101-00-CL1, 3045-102-00-CL1
REV
1.02
PRODUCT
SENTRY PRESSURE GOVERNOR
BY
AMS
8. Mounting & installation
8.1. Panel cutout dimensions (Sentry)
Mount the Sentry on the operator’s panel with four #6 screws and nuts.
Figure 4.
Installation dimensions in inches [millimeters].
8.2. Panel cutout dimensions (Twister)
Mount the Twister on the operator’s panel with four #6 screws and nuts.
Figure 5.
Installation dimensions in inches [millimeters].
