Enter the OEM 2 menu and select “Auto Mode” then press the INCREASE or DECREASE buttons to change to the
desired value (ENABLED, DISABLED). Press the SAVE button to save the OEM 2 menu items and exit the menu.
6.6.4. Idle Voltage
This menu item allows configuration of the analog idle offset voltage, displayed in “volts”. This option is only
available with the Analog Engine Control Method (section 6.6.2).
Note: This parameter is automatically set by the SENTRY when the Auto Scale routine is run (see section 6.3.5
for more information).
Enter the OEM 2 menu and select “Idle Voltag (Volts)” then press the INCREASE or DECREASE buttons to change
to the desired value (0 to 5 volts in 0.1 volt increments). Press the SAVE button to save the OEM 2 menu items
and exit the menu.
6.6.5. Idle Engine Speed (RPM)
This menu item allows configuration of the idle speed of the engine. Enter the OEM 2 menu and select “Idle Speed
(RPM)” then press the INCREASE or DECREASE buttons to change to the desired value (650 to 900 RPM in 1
RPM increments). Press the SAVE button to save the OEM 2 menu items and exit the menu.
6.6.6. Maximum Engine Speed (RPM)
This menu item allows configuration of the maximum speed of the engine. Enter the OEM 2 menu and select “Max.
Speed (RPM)” then press the INCREASE or DECREASE buttons to change to the desired value (1900 to 2500
RPM in 25 RPM increments). Press the SAVE button to save the OEM 2 menu items and exit the menu.
6.6.7. CAN Source ID
This menu item allows configuration of the source address for the PGN0 engine communication method. Enter the
OEM 2 menu and select “Source ID” then press the INCREASE or DECREASE buttons to change to the desired
address number (0-79). Press the SAVE button to save the OEM 2 menu items and exit the menu.
6.6.8. Pressure Time-Out (Seconds)
This menu item allows configuration of the low pressure time out. When the SENTRY is governing in pressure
mode and the pressure falls below 30 PSI the SENTRY will wait the configured number of seconds to attempt to
regain pressure before dropping to IDLE. Enter the OEM 2 menu and select “Press Time-Out (Sec)” then press the
INCREASE or DECREASE buttons to change to the desired value (3 to 10 seconds in 1 second increments).
Press the SAVE button to save the OEM 2 menu items and exit the menu.
