Infinity Supported Application 11
© 2014 AEM Performance Electronics
Infinity
Pin
Hardware
Reference
7100-XXXX-62
7101-XXXX-63
Function
Dest. Pin GM LS Hardware Specification Notes
C1-67 Analog_In_Temp_2
Intake Air
Temperature
IAT Sensor Signal
12 bit A/D, 2.49K pullup to
5V See "Air Temperature" Setup
Wizard f or selection.
C1-68
Harness_Analog_In_
Temp_3 Oil Temperature
Sensor
12 bit A/D, 2.49K pullup to
5V
See 1D table OilTempCal table
f or calibration data and OilTemp
[C] f or channel data.
C1-69 Stepper_2A Stepper 2A IAC Coil B High
Automotiv e, Programmable
Stepper Driv er, up to 28V
and ±1.4A
Be sure that each internal coil of
the stepper motor is properly
paired with the 1A/1B and 2A/2B
ECU outputs. Supports Bi-Polar
stepper motors only .
C1-70 Stepper_1A Stepper 1A IAC Coil A High
Automotiv e, Programmable
Stepper Driv er, up to 28V
and ±1.4A
Be sure that each internal coil of
the stepper motor is properly
paired with the 1A/1B and 2A/2B
ECU outputs. Supports Bi-Polar
stepper motors only .
C1-71 Stepper_2B Stepper 2B IAC Coil B Low
Automotiv e, Programmable
Stepper Driv er, up to 28V
and ±1.4A
Be sure that each internal coil of
the stepper motor is properly
paired with the 1A/1B and 2A/2B
ECU outputs. Supports Bi-Polar
stepper motors only .
C1-72 Stepper_1B Stepper 1B IAC Coil A Low
Automotiv e, Programmable
Stepper Driv er, up to 28V
and ±1.4A
Be sure that each internal coil of
the stepper motor is properly
paired with the 1A/1B and 2A/2B
ECU outputs. Supports Bi-Polar
stepper motors only .
C1-73 Power Ground Ground Power Ground
Connect directly to battery
ground.
C2-1 DBW2 Motor +
DBW Motor
Control Open
5.0A max Throttle Control
Hbridge Driv e
+12V to open
C2-2 DBW2 Motor -
DBW Motor
Control Close
5.0A max Throttle Control
Hbridge Driv e
+12V to close
C2-3 Power Ground Ground Power Ground
Connect directly to battery
ground.
C2-4 Injector 7 Injector 7 Fuel Injector 7 Control
Saturated or peak and hold,
3A max continuous
Injector 7
C2-5 Injector 8 Injector 8 Fuel Injector 8 Control
Saturated or peak and hold,
3A max continuous
Injector 8
C2-6 Injector 9 Injector 9
Saturated or peak and hold,
3A max continuous
Injector 9
C2-7 Injector 10 Injector 10
Saturated or peak and hold,
3A max continuous
Injector 10
