Security components and devices
The machine is equipped with the following security devices:
• An emergency push button
• A blocking door/shutter device
• A sensor for improper use of the rotation velocity
Emergency push button
For security reasons,it is recommended that all users know the positions and the modalities to use the red emergency
push button.
The emergency RED push button is assembled on the operator panel on the right part of the system. The pressing of this push
button permits the immediate cut off of the power supply and the stopping of the motor rotation . The restore of the normal
functioning of the equipment is possible rotating the emergency push button in clockwise direction . In case of emergency
stopping during the working cycle it is necessary execute the resetting procedures pushing STOP KEY .
Open door/shutter sensor
The machine is equipped with a security device which doesn’t permit the starting of the cycle if the door/shutter is in loading
position. During the working cycle the security device doesn’t permit the opening of the door/shutter.
Speed control sensor
On the machine is positioned a sensor able to notice the presence of a can with a high superior to 200 mm. The control system
guarantees rotation regime of 100g/m for cans with high superior to this dimension, it permits, on the contrary, rotation of 100
or 200 rpm for cans with high inferior to this dimension . This situation guarantees a correct dynamic arrangement of the
equipment . If the operator set a high velocity with a big can the system gives an error signal and it starts the rotation with a
suitable velocity.
INSTALLATION CONDITIONS
Before installation please make sure of the following:
Place the Ferraris Mixer on a firm and leveled floor
• 220-240 VOLTAGE: Provide a grounded power supply of 220 / 240 Volt (or otherwise specified following local situations),
which has a differential (MINIMUM 30mA), a magnetothermic protection of 16 Amp.
• 115 VOLTAGE: Provide a grounded power supply of 115 Volt (or otherwise specified following local situations), which has a
differential (MINIMUM 30mA), a magnetothermic protection of 25 Amp.
Environmental conditions should be within the following limits:
Ambient air temperature : 10 to 40 ° C
Relative humidity : 30 to 90 %
During the installation it is advisable to use protective gloves to avoid hand injuries
This mixer must not be installed in an explosion proof classified working area
In case an extension is needed, please make sure it is correctly dimensioned,
according to the electrical absorption of the mixer
One mixer only (therefore no other machinary) is to be connected to a single
magnetothermic switch
