JK Rear Rock Door 4 Kit 88003
2. Ensure all wires, hoses, cables, etc. are properly
connected and there is ample slack.
Kit Parts List
Qty. Description
1 Door (driver)
1 Door (passenger)
1 Label (logo)
2 Label (warning)
1 Pad (cover, driver)
1 Pad (cover, passenger)
2 Pad (long)
2 Pad (short)
1 ZP119 (Hardware bag, 88003)
4 Hinge
1 ZH28 (Hardware bag, 88003)
4 Bolt (1/4”-20 x 1”)
8 Bolt (5/16” x 1” button head)
4 Bolt (7/16”-14 x 3-3/4”)
2 Cap (urethane)
1 Latch (driver)
1 Latch (passenger)
2 Nut (7/16”-14 Nylock)
4 Plug (plastic)
4 Sleeve [Not Needed For Rear Doors]
4 Washer (1/4” SAE)
8 Washer (7/16” nylon)
2 Weather-strip
WARNING
This product is for Off-Road use only. It is NOT
intended as a safety restraint device. Always make
sure all occupants are wearing seat belts at all times.
NOTE
All warranty information, instruction sheets, and other
documents regarding the installation of this product
must be retained by the vehicle owner. Information
contained in the instructions and on the warranty card
will be required for any warranty claims. The vehicle
owner needs to understand the modifications made to
the vehicle and how they affect vehicle handling and
performance. Failure to provide the customer with this
information can result in damage to the vehicle and
severe personal injury.
