JK Rear Rock Door 2 Kit 88003
c. Unplug wire harness to each door.
d. With door open, lift up and remove O.E. door
from two hinges and vehicle.
e. Repeat above substeps for passenger side door.
Install Rock Doors
1. Rear driver door
a. Install two kit hinges onto kit door (driver) with
four kit bolts (5/16 x 1” button head). Snug, but
DO NOT TIGHTEN.
b. Install kit cap onto kit door (driver).
Pin
Restraint
Strap
Door
Kit Hinge
Kit Bolt
(5/16” x 1”
button head)
c. Install kit plug onto kit door (driver).
d. Install kit door (driver) onto two O.E. hinges with
two kit bolts (7/16”-14 x 3-3/4”) and four kit
washers (7/16” nylon).
Kit Caps
Kit Plug (Urethane)
Kit Bolt
(7/16”-14x
3-3/4”)
Kit Door
(Driver)
Kit Bolt
(7/16”-14 x
3-3/4”)
Kit Washers
(7/16” Nylon)
Kit Washers
(7/16” Nylon)
