MUSCLE (Midship) Pumps Installation, Operation, and Maintenance Manual
p/n: 029-0020-63-0
Nozzle Size vs. Pressure
Appendix F: Nozzle Size vs. Pressure
Table F-1: Nozzle Flow and Pressure Ratings (Part 1)
GPM (LPM) at Various Nozzle Sizes
Nozzle
Pressure
Nozzle Size in Inches (millimeters)
PSI (kPa)
1/2” (13)
5/8” (16)
3/4” (19)
7/8” (22)
1.0” (25.4) 1-1/8” (29) 1-1/4” (32) 1-3/8” (35)
30 (207)
41 (155)
64 (242)
92 (348)
125 (473)
163 (617)
206 (780)
254 (962)
308 (1,166)
35 (241)
44 (167)
69 (261)
99 (375)
135 (511)
176 (666)
222 (840)
275 (1,041) 332 (1,257)
40 (276)
47 (178)
73 (296)
106 (401)
144 (545)
188 (711)
238 (901)
294 (1,113) 355 (1,334)
45 (310)
50 (189)
78 (295)
112 (424)
153 (579)
199 (753)
252 (954)
311 (1,177) 377 (1,437)
50 (345)
53 (201)
82 (310)
118 (447)
161 (610)
210 (795)
266 (1,007) 328 (1,242) 397 (1,503)
55 (379)
55 (208)
86 (326)
124 (469)
169 (640)
220 (833)
279 (1,056) 344 (1,302) 417 (1,647)
60 (414)
58 (220)
90 (341)
130 (492)
176 (666)
230 (871)
291 (1,102) 360 (1,363) 435 (1,363)
62 (427)
58 (220)
91 (345)
132 (500)
179 (678)
234 (886)
296 (1,121) 366 (1,385) 442 (1,673)
64 (441)
59 (223)
93 (352)
134 (507)
182 (689)
238 (901)
301 (1,139) 371 (1,404) 449 (1,700)
66 (455)
60 (227)
94 (356)
136 (515)
185 (700)
241 (912)
305 (1,155) 377 (1,427) 456 (1,726)
68 (469)
61 (231)
96 (363)
138 (522)
188 (711)
245 (927)
310 (1,174) 383 (1,450) 463 (1,753)
70 (482)
62 (235)
97 (367)
140 (530)
190 (719)
248 (939)
315 (1,192) 388 (1,469) 470 (1,779)
72 (496)
63 (238)
99 (375)
142 (538)
193 (731)
252 (954)
319 (1,208) 394 (1,492) 477 (1,806)
74 (510)
64 (242)
100 (379)
144 (545)
196 (742)
255 (965)
323 (1,223) 399 (1,510) 483 (1,828)
76 (524)
65 (246)
101 (382)
146 (553)
198 (750)
259 (980)
328 (1,242) 405 (1,553) 490 (1,855)
78 (538)
66 (250)
103 (390)
148 (560)
201 (761)
262 (992)
332 (1,257) 410 (1,552) 496 (1,878)
80 (552)
66 (250)
104 (394)
150 (568)
203 (768)
266 (1,007) 336 (1,272) 415 (1,571) 502 (1,900)
85 (586)
68 (257)
107 (405)
154 (583)
210 (795)
274 (1,037) 347 (1,314) 428 (1,620) 518 (1,961)
90 (620)
70 (265)
110 (416)
159 (602)
216 (818)
282 (1,067) 357 (1,351) 440 (1,666) 533 (2,018)
95 (655)
72 (273)
113 (428)
163 (617)
222 (840)
289 (1,094) 366 (1,386) 452 (1,711) 547 (2,071)
100 (689)
74 (280)
116 (439)
167 (362)
228 (863)
297 (1,124) 376 (1,423) 464 (1,756) 562 (2,127)
105 (724)
76 (288)
119 (451)
171 (647)
233 (882)
304 (1,151) 385 (1,457) 476 (1,802) 575 (2,177)
110 (758)
78 (295)
122 (462)
175 (663)
239 (905)
311 (1,117) 394 (1,492) 487 (1,844) 589 (2,230)
115 (793)
80 (303)
125 (473)
179 (678)
244 (924)
319 (1,208) 403 (1,526) 498 (1,885) 602 (2,279)
120 (827)
81 (307)
127 (481)
183 (712)
249 (943)
325 (1,203) 412 (1,560) 509 (1,927) 615 (2,328)
