Black Box Console Server user guide
52
4.
Key a maximum of sixteen alphanumeric characters.
To change the secret you must delete the host and then add it again; when you add
a host you are prompted for a secret.The first host entered becomes the primary
authentication/accounting host, the next host entered becomes the secondary host.
You can enter a maximum of two hosts in each of the fields.
You must enter the same secret in the RADIUS host (see your RADIUS
documentation); the secret is not transmitted over the network. Note that to set
RADIUS authentication on/off, go to back to the Main Menu and select ‘server
configuration’. See
Setting up an IP address on page 33
.
5.
Select ‘change radius settings’, you are presented with the following (shown in
the next picture):
The RADIUS parameters are described in
RADIUS parameters description on
6.
When you have completed the form, press
with the following display:
